Diesel Engine Generating Sets
As diesel is conveniently transported and stored for use when required, diesel engines are generally the most common prime movers for generating sets.
Our standard range of diesel engine generators or gensets is shown below:
| Genset Model | Engine | Alternator | 50 Hz | 60 Hz | PDF Download | ||||||||
| Prime | Standby | Prime | Standby | ||||||||||
| RPM | kVA | kW | kVA | kW | RPM | kVA | kW | kVA | kW | ||||
| 400 Series | |||||||||||||
| P9.5-4 | 403D-11G | LL1114B | 1500 | 8.5 | 6.8 | 9.5 | 7.6 | 1800 | 10.0 | 8.0 | 11.0 | 8.8 |  |
| P13.5-6 | 403D-15G | LL1114D | 1500 | 12.5 | 10.0 | 13.5 | 10.8 | 1800 | 15.0 | 12.0 | 16.5 | 13.2 | |
| P18-6 | 404D-22G1 | LL1114H | 1500 | 16.5 | 13.2 | 18.0 | 14.4 | 1800 | 20.0 | 16.0 | 22.0 | 17.6 | |
| P22-6 | 404D-22G | LL1114M | 1500 | 20.0 | 16.0 | 22.0 | 17.6 | 1800 | 22.5 | 18.0 | 25.0 | 20.0 | |
| 1103 Series | |||||||||||||
| P33-3 | 1103A-33G1 | MJB 160 MB4 | 1500 | 30.0 | 24.0 | 33.0 | 26.4 | 1800 | 33.8 | 27.0 | 37.5 | 30.0 | |
| P33-6 | 1103D-33G3 | MJB 160 MB4 | 1500 | 30.0 | 24.0 | 33.0 | 26.4 | – | – | – | – | – | |
| P50-3 | 1103A-33TG1 | MJB 200 SB4 | 1500 | 45.0 | 36.0 | 50.0 | 40.0 | 1800 | 50.0 | 40.0 | 56.3 | 45.0 | |
| P50-4 | 1103C-33TG2/3 | MJB 200 SB4 | 1500 | 45.0 | 36.0 | 50.0 | 40.0 | – | – | – | – | – | |
| P55-3 | 1103A-33TG2 | MJB 200 SB4 | 1500 | 50.0 | 40.0 | 55.0 | 44.0 | 1800 | 56.3 | 45.0 | 62.5 | 50.0 | |
| P65-5 | 1103A-33TG2 | MJB 200 MA4 | 1500 | 60.0 | 48.0 | 65.0 | 52.0 | 1800 | 68.8 | 55.0 | 75.0 | 60.0 | |
| 1104 Series | |||||||||||||
| P55-4 | 1104C-44TG2/3 | MJB 200 SB4 | 1500 | 50.0 | 40.0 | 55.0 | 44.0 | – | – | – | – | – | |
| P65-6 | 1104D-44TG2/3 | MJB 200 MA4 | 1500 | 60.0 | 48.0 | 65.0 | 52.0 | – | – | – | – | – | |
| P88-3 | 1104A-44TG2 | MJB 200 LA4 | 1500 | 80.0 | 64.0 | 88.0 | 70.4 | 1800 | 90.0 | 72.0 | 100.0 | 80.0 | |
| P88-6 | 1104D-E44TAG1 | MJB 200 LA4 | 1500 | 80.0 | 64.0 | 88.0 | 70.4 | – | – | – | – | – | |
| P110-3 | 1104C-44TAG2 | MJB 225 MA4 | 1500 | 100.0 | 80.0 | 110.0 | 88.0 | 1800 | 113.0 | 90.4 | 125.0 | 100.0 | |
| P110-6 | 1104D-E44TAG2 | MJB 225 MA4 | 1500 | 100.0 | 80.0 | 110.0 | 88.0 | – | – | – | – | – | |
| 1006 Series | |||||||||||||
| P150-3 | 1006TAG | MJB 250 MA4 | 1500 | 135.0 | 108.0 | 150.0 | 120.0 | 1800 | 150.0 | 120.0 | 165.0 | 132.0 | |
| P165-1 | 1006TAG2 | LL3014F | 1500 | 150.0 | 120.0 | 165.0 | 132.0 | – | – | – | – | – | |
| P165-3 | 1006TAG2 | MJB 250 MA4 | 1500 | 150.0 | 120.0 | 165.0 | 132.0 | – | – | – | – | – | |
| 1106 Series | |||||||||||||
| P150-4 | 1106C-E66TAG2 | MJB 250 MA4 | 1500 | 135.0 | 108.0 | 150.0 | 120.0 | – | – | – | – | – | |
| P165-4 | 1106C-E66TAG3 | MJB 250 MA4 | 1500 | 149.9 | 119.9 | 165.0 | 132.0 | – | – | – | – | – | |
| P200-3 | 1106A-70TAG3 | MJB 250 MB4 | 1500 | 180.0 | 144.0 | 200.0 | 160.0 | – | – | – | – | – | |
| P200-4 | 1106C-E66TAG4 | MJB 250 MB4 | 1500 | 180.0 | 144.0 | 200.0 | 160.0 | 1800 | 196.9 | 157.5 | 218.8 | 175.0 | |
| P220-3 | 1106A-70TAG4 | MJB 250 LA4 | 1500 | 200.0 | 160.0 | 220.0 | 176.0 | – | – | – | – | – | |
| 1306 Series | |||||||||||||
| P249H-3 | 1306A-E87TAG4 | MJB 250LA4 | – | – | – | – | – | 1800 | 225.0 | 180.0 | 250.0 | 200.0 | |
| P250H-3 | 1306A-E87TAG4 | MJB 250LB4 | 1500 | 230.0 | 184.0 | 250.0 | 200.0 | 1800 | 240.0 | 192.0 | 265.0 | 212.0 | |
| P275H-3 | 1306A-E87TAG6 | MJB 250LB4 | 1500 | 250.0 | 200.0 | 275.0 | 220.0 | – | – | – | – | – | |
| 1606 Series | |||||||||||||
| P300H-1 | 1606A-E93TAG4 | LL5014J | 1500 | 275.0 | 220.0 | 300.0 | 240.0 | 1800 | 312.5 | 250.0 | 343.8 | 275.0 | |
| P330H-1 | 1606A-E93TAG4 | LL5014F | 1500 | 300.0 | 240.0 | 330.0 | 264.0 | – | – | – | – | – | |
| 2206 Series | |||||||||||||
| P400-1 | 2206A-E13TAG2 | LL6114B | 1500 | 350.0 | 280.0 | 400.0 | 320.0 | _ | _ | _ | _ | _ | |
| P438-1 | 2206A-E13TAG5 | LL6114B | – | – | – | – | – | 1800 | 400.0 | 320.0 | 437.5 | 350.4 | |
| P450-1 | 2206A-E13TAG2 | LL6114C | 1500 | 400.0 | 320.0 | 450.0 | 360.0 | _ | _ | _ | _ | _ | |
| P501-1 | 2206A-E13TAG6 | LL6114B | – | – | – | – | – | 1800 | 437.5 | 350.0 | 500.0 | 400.0 | |
| 2506 Series | |||||||||||||
| P500-1 | 2506A-E15TAG1 | LL6114D | 1500 | 455.0 | 364.0 | 500.0 | 400.0 | – | – | – | – | – | |
| P550-1 | 2506A-E15TAG2 | LL6114F | 1500 | 500.0 | 400.0 | 550.0 | 440.0 | – | – | – | – | – | |
| P563-1 | 2506A-E15TAG3 | LL6114D | – | – | – | – | – | 1800 | 512.5 | 410.0 | 562.5 | 450.0 | |
| P625-1 | 2506A-E15TAG4 | LL6114F | – | – | – | – | – | 1800 | 568.8 | 455.0 | 625.0 | 500.0 | |
| 2806 Series | |||||||||||||
| P605-1 | 2806A-E18TAG1 | LL7024F | 1500 | 550.0 | 440.0 | 605.0 | 484.0 | – | – | – | – | – | |
| P660-1 | 2806A-E18TAG1A | LL7024F | 1500 | 600.0 | 480.0 | 660.0 | 528.0 | – | – | – | – | – | |
| P688-1 | 2806A-E18TAG1A | LL7024F | – | – | – | – | – | 1800 | 625.0 | 500.0 | 687.5 | 550.0 | |
| P700-1 | 2806A-E18TAG2 | LL7024H | 1500 | 635.0 | 508.0 | 700.0 | 560.0 | – | – | – | – | – | |
| P750-1 | 2806A-E18TAG3 | LL7024F | – | – | – | – | – | 1800 | 681.3 | 545.0 | 750.0 | 600.0 | |
| 4006 Series | |||||||||||||
| P730P1/P800E1 | 4006-23TAG2A | LL7024L | 1500 | 730.0 | 584.0 | 800.0 | 640.0 | 1800 | 735.0 | 588.0 | 844.0 | 675.2 | |
| P800P1/P900E1 | 4006-23TAG3A | LL7024P | 1500 | 800.0 | 640.0 | 900.0 | 720.0 | 1800 | 835.0 | 668.0 | 938.0 | 750.4 | |
| 4008 Series | |||||||||||||
| P910P1/P1000E1 | 4008TAG1A | LL7124P | 1500 | 910.0 | 728.0 | 1000.0 | 800.0 | – | – | – | – | – | |
| P1000P1/P1100E1 | 4008TAG2A | LL7124P | 1500 | 1000.0 | 800.0 | 1100.0 | 880.0 | – | – | – | – | – | |
| 4012 Series | |||||||||||||
| P1250P3/P1375E3 | 4012-46TWG2A | LL8224H | 1500 | 1250.0 | 1000.0 | 1375.0 | 1100.0 | – | – | – | – | – | |
| P1350P1/P1500E1 | 4012-46TWG3A | LL8224L | 1500 | 1350.0 | 1080.0 | 1500.0 | 1200.0 | – | – | – | – | – | |
| P1500P3/P1650E3 | 4012-46TAG2A | LL8224N | 1500 | 1500.0 | 1200.0 | 1650.0 | 1320.0 | – | – | – | – | – | |
| P1700P1/P1875E1 | 4012-46TAG3A | LL9224F | 1500 | 1700.0 | 1360.0 | 1875.0 | 1500.0 | – | – | – | – | – | |
| 4016 Series | |||||||||||||
| P1750/P1925E | 4016TAG | LL9224F | 1500 | 1750.0 | 1400.0 | 1925.0 | 1540.0 | – | – | – | – | – | |
| P1825/P2000E | 4016TAG1A | LL9224F | 1500 | 1825.1 | 1460.1 | 2000.0 | 1600.0 | – | – | – | – | – | |
| P2000-1/P2000-1E | 4016-61TRG1 | LL9224F | 1500 | 1850.0 | 1480.0 | 2000.0 | 1600.0 | – | – | – | – | – | |
| P2000/P2250E | 4016TAG2A | LL9224H | 1500 | 2000.0 | 1600.0 | 2249.2 | 1799.4 | – | – | – | – | – | |
| P2250-1 | 4016-61TRG2 | LL9224H | 1500 | 2000.0 | 1600.0 | 2250.0 | 1800.0 | – | – | – | – | – | |
| P2500-1 | 4016-61TRG3 | LL9224P | 1500 | 2250.0 | 1800.0 | 2500.0 | 2000.0 | – | – | – | – | – | |
